Avaya 1120E IP NTYS03BFGS

Watch On YouTube here: Avaya 1120e IP  Desk PhoneReview
Via: RQ Communications Channel

Avaya 1120E NTYS03BFGS IP Deskphone – VoIP Phone

The Avaya 1120E is an intermediate-level desktop VoIP Phone that is particularly suited for office workers and administrative personnel. The application navigation is flexible, with the use of standard USB mice and keyboards as supported from the phone’s integrated USB port. It also provides support for SIP protocols that will allow for easy deployment on any Nortel or third party servers.

The 1120E IP Deskphone also enables the presentation of converged voice and data applications, leveraging its integrated high-resolution graphical, eight-level grayscale display and brings voice and data to the desktop by connecting directly to a Local Area Network (LAN) through an Ethernet connection

Features

Brand: Avaya

Product Type: IP Phones

Additional Part Numbers:

• Avaya 1120e
• NTYS03BFE6
• NTYS03
• NTYS03BFGS
• NTYS03AFE6

Function Buttons:

• Speakerphone button
• directory button
• goodbye button
• headset button
• mute button
• hold button

Volume Control: Yes

Ringer Control: Yes

Indicators: New message indicator, visual ringer light

Firmware Upgradable: Yes

Additional Features: Compatible with Bluetooth headsets, built-in Bluetooth audio gateway

Main Features: Integrated Ethernet switch

VoIP Protocols: SIP

Voice Codecs: G.722, G.729a, G.729ab, G.711u, G.711a

Lines Supported: Multiline

Quality of Service: IEEE 802.1Q (VLAN), Differentiated Services (DiffServ), IEEE 802.1p

Display:

High-resolution, backlit, graphical, pixel based display, combined with a flexible five-position adjustable foot stand placement, optimizes viewing in varied lighting conditions

Navigation:

Four-way navigation cluster with new “Enter/Send” key maximizes user choice and flexibility in navigation

USB:

Integrated USB port powers standard USB mice and keyboards, providing input and navigation options for application interaction and simpler menu selection

Integrated 10/100/1000 Base-T Ethernet switch with LAN and PC ports:

Reduces costs, enabling a single cable drop to support both the phone and a collocated PC

Gigabit Ethernet:

Supports Gigabit Ethernet, positioning the phone’s internal switch to accommodate growing multimedia-intensive, PC-based applications, thus aligning with investment made at the wiring closet

Additional Resources

• [PDF] IP Phone 1120e User Guide
• [PDF] IP 1120e – Quick Reference Card
